发动机型号

Engine Model

云内490增压

Cloud 490 Boost

A

车宽（标准轮胎）mm

Vehicle width (standard tires) mm

1700

额定功率 kw

Rated power kw

58

B

转弯半径 mm

Turning radius mm

4350

标定转速 rpm

Calibration speed rpm

2400

C

液压马达额定扭矩N.m

Rated torque of hydraulic motor N.m

8000

zui大行驶速度 km/h

Maximum driving speed km/h

20

D

系统安全压力 Mpa

System safety pressure (Mpa)

25

轮胎型号

Tyre model

16-70-16（Big20.5）

E

燃油箱容积 L

Fuel tank volume L

50

搅拌桶容积m³

Mixing drum volume m3

1.2

F

机油箱容积 L

Oil tank volume L

50

搅拌桶直径X高 mm

Mixing drum diameter X height mm

1800X630

G

自重 kg

Dead weight kg

4350

搅拌转速rpm

Stirring speed rpm

22

H

变矩器

torque converter

265

液压系统额定流量L /min

Rated flow of hydraulic system L /min

50

I

车桥

Axle

小轮边

small wheel side

至驾驶室顶高度mm

Height to cab top mm

2600

J

车身总长（收斗时）mm

Overall body length (when collecting bucket) mm

  4500

K

外形尺寸  长*宽*高 mm

Dimensions (H x W x H) mm

5400*1850*2860
